Equipment/Devices

It is capable to generate configurable voltage supply at the terminal.

More info

It emulates electric power lines between the power source and the cabinets connected to the microgrid generating the power line losses.

More info

Each one of these cabinets has the ability to behave like several different electric devices:

• generators.
• loads.
• storage systems.

More info

This flexible platform allows to test various systems and programs related to batteries (first and second life) with single-phase or three-phase system.

More info

Devices available for projects in the smartlab:

• Oscilloscope Tektronix MSO58B
• Oscilloscope Agilent MSO9254A
• Oscilloscope Yokogawa Scopecorder DL-750
• Power analyzer Yokogawa WT1600
• Power analyzer Yokogawa WT500
• Fluke 435 Power Quality Analyzer
• …

More info

This explosion-proof chamber with two compartments it’s used to test the limits of the batteries (commercial and prototypes) in a safer environment, along with a multiple gas sensor, to detect leakage of gases that are not perceptible to humans, but which are very harmful to health in relative quantities.

More info

Scalable AC resistive load, with remote or local control, to test the grid or microgrid in different situations.

More info

Bidirectional power supplies which can test up to 500 V and 216 A.

Equipment:

• 2x Battery Tester 500V 216A: More info
• 1x Battery Tester 80V 170A: coming soon…

Rack with temperature chambers and battery cyclers with various channels that can test up to 6 V and 80 A each.

Equipment:

• 1x Multi-Zone Temperature Chamber: More info
• 1x Battery Tester 10Ch 6V 80A: More info
• 2x Battery Tester 80V 60A: coming soon…

The OP4510 is a complete simulation system operating with a Kintex7 FPGA. It is designed to be used as a desktop (or shelf top)simulator. It contains a powerful Target Computer and a flexible, high-speed Front End Processor and a signal conditioning stage. The design makes it easy to use with standard connectors (DB37, DB9).

More info
